Driver for LED luminaire 65W - 1750mA - IP65

Reference: DRIVER65W-1750MA

Driver for 65W LED luminaire with 1750mA range. It is a current and voltage transformer for LED luminaires. Model that has IP65, which allows its use both outdoors and indoors.

Output: DC20-40Vdc 1750mA - GXTRONIC

65W
AC110v-260
IP65-Outdo
170x55x35m

Brightness calculation

1.Technical characteristics of the luminaire:

Indicate the technical characteristics of the LED projector or luminaire you wish to install:

Lumens (Lm): Luminous flux of the luminaire to be installed.

Angle (º): Angle of the luminaire to be installed.

Height (m): Total height in meters of the space (room) (axis "z").

2.Calculation of the individual capacity of the chosen luminaire:

Calculation of the luminous power and luminance of the LED luminaire defined in point 1.

Illuminated radius:

Total illuminated covered area:

3.Theoretical result:

Result of the luminous power and luminance.

Luminous Intensity (Candela - cd)

Surface illumination (lx)

Fast and secure delivery

Download technical datasheet

We offer professional prices for LED lighting

€19.70

No tax

Download PDF

Description
Product Details

Driver for LED luminaire 65W - 1750mA - IP65

The GXTRONIC LED luminaire driver with a 50W power range and 1750mA is a current transformer designed to power LED luminaires, ensuring their proper operation and optimal performance. This particular model has a capacity of 50 watts and a current range of 1750 mA, making it suitable for a wide variety of lighting applications.

One of the main features of this driver is that it has an IP65 housing, making it dust and water-resistant, allowing for use in both indoor and outdoor environments, ideal for commercial, industrial, and residential applications.

In addition, this driver has an input voltage of 110-260 volts AC, making it compatible with a wide variety of electrical power sources, and a frequency of 50/60 Hz, ensuring stable and consistent power supply. The 0.95 power factor indicates high energy efficiency and reduces energy consumption compared to drivers with lower power factors.

Another important feature is its operating temperature, with an ambient temperature range of -45ºC to 75ºC, making it suitable for applications in a wide variety of climates and environments.

Regarding the output, the driver offers a DC current of 20-40 volts, allowing for stable and consistent power supply to the LED luminaire, resulting in increased durability and energy efficiency.

In summary, the GXTRONIC LED luminaire driver with a 50W power range and 1750mA is a highly efficient and durable current transformer designed to provide safe and reliable power supply for LED luminaires in a wide variety of lighting applications, both indoor and outdoor. With a wide range of features and specifications, this driver is an excellent choice for those seeking a high-quality and high-performance lighting solution.

Reference DRIVER65W-1750MA

Data sheet

REFERENCE: DRIVER65W-1750MA
Rated Power: 65W
Nominal Voltage: AC110v-260v
Construction Material: Aluminium +PMMA
Certifications: CE - ROHS
IP: IP65-Outdoor
Dimensions (mm): 170x55x35mm
Power Factor (PF): 0.95
Frequency (Hz): 50/60Hz
Other Information: Exit: DC20-40V 1750mA - GXTRONIC
Warranty Years: 5
